SIMRAD NSX 3009 / Touch / s 3u1 aktivnim slikovnim pretvaračem
Broj artikla SVB: 81856
Broj proizvođača: 000-15369-001
Zahvaljujući inovativnom, modernom korisničkom sučelju s moćnim navigacijskim mogućnostima i podrškom za C-MAP, vidjet ćete sve kao nikad prije. NSX kombinira jasno i nekomplicirano korisničko sučelje s grafikom visoke rezolucije i može se lako proširiti (npr. radar, sonar, autopiloti itd.). Uključena je aktivna slikovna sonda. Detalji o proizvodu
Cjenik:
2.123,75 EUR
samo
1.817,17 EUR
-14%
Štedite: 306,58 EUR
Dostupno na 31.07.2026
Nešto ne radi?
Ako niste preusmjereni na PayPal, to bi moglo biti zbog postavki vašeg preglednika. Provjerite i po potrebi deaktivirajte postavku "Sakrij IP adresu" u postavkama -> Safari -> Sakrij IP adresa. Također provjerite ima li u vašem pregledniku ažuriranja.
Ako niste preusmjereni na PayPal, to bi moglo biti zbog postavki vašeg preglednika. Provjerite i po potrebi deaktivirajte postavku "Sakrij IP adresu" u postavkama -> Safari -> Sakrij IP adresa. Također provjerite ima li u vašem pregledniku ažuriranja.
Već koristite ovaj članak?
Dodaj u moj brod odmah.
Dostupne varijante
Na prvi pogled!
Podaci o proizvodu
- Broj artikla SVB 81856
- EAN 9420064111947
- Broj proizvođača 000-15369-001
- Opis SIMRAD - NSX 3009 višenamjenski zaslon s 3IN1 Active Imaging sondom
- Niz NSX
- Veličina zaslona 9 inča
- Rezolucija 1280 x 720 px
- Kut gledanja 85 °
- Svjetlina zaslona 1200 Gnjide
- Radni napon 12 V
- Način rada Ekran na dodir
- NMEA2000 Da
- NMEA0183 Ne
- WiFi Da
- Bluetooth Da
- Ethernet / mreža Da
- Mogućnost radara Da
- Kontrola tableta Ne
- Sonarni modul Da
- Vrsta sonara CHIRP / Fishfinder, DownScan, SideScan, Numerička dubina
- Kut gledanja prema dolje, Ustranu
- Maksimalna dubina 305 m
- Kompatibilne Navico sonde P79, P319, HDI, HST-WSBL, TotalScan, Active Imaging
- Podrška za pomorske karte Da
- Pomorske karte C-MAP REVEAL X, C-MAP DISCOVER X
- Širina ugradnje 227 mm
- Visina ugradnje 135 mm
- Sa pretvaračem Da
- Pogled sonara Riba, Struktura dna
- IP klasa zaštite IPX7
Detalji o proizvodu
Note
The Simrad NSX series only supports C-MAP DISCOVER X and C-MAP REVEAL X charts.
Crystal clear views, modern and straightforward interface
The NSX features a SolarMAX IPS touch screen and delivers crystal clear views of chart detail, structure and bottom contours. The display is easy to view even in sunlight or through polarised lenses. Featuring high-resolution visuals and enhanced day and night modes, plus a clean and straightforward user interface with screen customisation and fully editable instruments bar.
Intuitive chart presentation
C-MAP nautical charts (DISCOVER X and REVEAL X) are available in different cruising areas and include full vector charts as well as tide and current projections. They include high-resolution bathymetry, improved route planning and accurate contour lines. Touch an object on the chart (e.g. a marina or a marker buoy) to access additional information, such as a detailed description, opening hours, facilities and much more.
Simrad App and Setup Wizzard
The Setup Wizard helps you set up and configure your NSX quickly and easily. Step-by-step instructions make engine and tank set-up, radar calibration, autopilot optimisation and much more a breeze.
In combination with the free Simrad App, software updates can be easily downloaded and installed. You can also plan trips and then transfer data to the multifunction display, including routes and waypoints. Available from the AppStore and Google Play.
Includes Active Imaging transducer
Navico's Active Imaging 3-in-1 transducer is included in the delivery contents and combines the latest sonar technologies with traditional frequencies. The transducer achieves incredibly detailed and high-resolution sonar images without compromising range. It gives you high-resolution images below (Traditional, DownScan) and to the sides of your boat (SideScan). The transducer also measures the current water temperature. Includes bracket and connection cable. Connector: 9 pins.
System extensions
The NSX series supports a wide range of system extensions. Identify potential hazards with pulse compression radars, stay on course with an optional autopilot and more. NMEA2000 and Ethernet connectivity can be used to connect the devices.
Further features at a glance:
Technical data
The Simrad NSX series only supports C-MAP DISCOVER X and C-MAP REVEAL X charts.
Crystal clear views, modern and straightforward interface
The NSX features a SolarMAX IPS touch screen and delivers crystal clear views of chart detail, structure and bottom contours. The display is easy to view even in sunlight or through polarised lenses. Featuring high-resolution visuals and enhanced day and night modes, plus a clean and straightforward user interface with screen customisation and fully editable instruments bar.
Intuitive chart presentation
C-MAP nautical charts (DISCOVER X and REVEAL X) are available in different cruising areas and include full vector charts as well as tide and current projections. They include high-resolution bathymetry, improved route planning and accurate contour lines. Touch an object on the chart (e.g. a marina or a marker buoy) to access additional information, such as a detailed description, opening hours, facilities and much more.
Simrad App and Setup Wizzard
The Setup Wizard helps you set up and configure your NSX quickly and easily. Step-by-step instructions make engine and tank set-up, radar calibration, autopilot optimisation and much more a breeze.
In combination with the free Simrad App, software updates can be easily downloaded and installed. You can also plan trips and then transfer data to the multifunction display, including routes and waypoints. Available from the AppStore and Google Play.
Includes Active Imaging transducer
Navico's Active Imaging 3-in-1 transducer is included in the delivery contents and combines the latest sonar technologies with traditional frequencies. The transducer achieves incredibly detailed and high-resolution sonar images without compromising range. It gives you high-resolution images below (Traditional, DownScan) and to the sides of your boat (SideScan). The transducer also measures the current water temperature. Includes bracket and connection cable. Connector: 9 pins.
System extensions
The NSX series supports a wide range of system extensions. Identify potential hazards with pulse compression radars, stay on course with an optional autopilot and more. NMEA2000 and Ethernet connectivity can be used to connect the devices.
Further features at a glance:
- Integrated GPS antenna
- Multilingual user interface
- Change chart settings in a flash
- Switch between applications quickly at the touch of a button
- Switch from split view to full screen with just one touch
- Waterproof to IPX6 and IPX7
Technical data
| Display size | 9" |
| Resolution | 1280 x 720 px |
| Brightness | >1200 nits |
| Viewing angle | 85° |
| Power supply | 10-17 V DC |
| Max. power consumption | 18.8 W (1360 mA @ 13.8 V) |
| Rec. fuse | 3 A |
| GPS | Yes, integrated (10 Hz, 32 channel) |
| NMEA2000 | Yes (1x) |
| Ethernet | Yes (1x) |
| Bluetooth | Yes (4.0) |
| AIS compatibility | Yes (via NMEA2000) |
| Radar compatibility | Yes |
| Card slot | 1x microSD |
| Chart support | C-MAP Discover, C-MAP Reveal |
| Compass distance | min. 50 cm |
| Operating temperature | -15 to +55 ° C |
| Storage temperature | -20 to +60 °C |
| Waterproof | IPX6 and IPX7 |
| Dimensions (WxHxD) | 239 x 149 x 81 mm (without bracket) 263 x 173 x 81 mm (with bracket) |
| Weight: | 1.2 kg |
| Languages | Danish, Dutch, English, Finnish, French, German, Greek, Italian, Norwegian, Portuguese, Spanish and Swedish |
Značajke
Otkrijte značajke koje ovaj proizvod izdvajaju. Od tehničkih detalja do posebnih funkcija – saželi smo sve ključne informacije za vas.
Veličina zaslona
9 inča
Način rada
Ekran na dodir
Ne
Mogućnost radara
Da
Kut gledanja
prema dolje
Ustranu
Sa pretvaračem
Opseg isporuke
- Prikaz
- Kabel za napajanje, 4-pinski
- Gimbal nosač
- Aktivni slikovni 3-u-1 pretvornik
- Suncobran
- Komplet nosača za montažu
Dokumenti
Crtanje
PDF (464,25 KB)
Priručnik
PDF (2,70 MB)
Priručnik
PDF (3,12 MB)
Priručnik
PDF (2,21 MB)
Kratki priručnik
PDF (12,77 MB)
Sigurnost proizvoda
